Embedded Board
-
VSX-6119-FC-D-V2
System on Module - ICOP Proprietary$170.00- DM&P SoC Vortex86SX- 300MHz
- 256MB DDR2 onboard
- 2S / U / LPT / 16GPIO
- Onboard 2MB SPI Flash
- 128-pin module, 64-pin 16-bit x-ISA, 64-pin I / O
- Onboard 1GB EmbedDisk
- 65 x 45mm, DC +5V @300mA
-
VSX-6101-V2
System on Module - ICOP Proprietary$136.00- DM&P SoC Vortex86SX- 300MHz
- 128MB DDR2 onboard
- 4S / 3U / LAN / 20GPIO / CF
- Onboard 2MB SPI Flash
- 48-pin module
- 64 x 46mm, DC +5V @320mA
- Optional: up to 32 GPIO
-
VSX-6100-V2
System on Module - ICOP Proprietary$149.00- DM&P SoC Vortex86SX- 300MHz
- 256MB DDR2 onboard
- 5S / 3U / LAN / 28GPIO / CF
- Onboard 2MB SPI Flash
- 68-pin module
- 90 x 46mm, DC +5V @ 300mA
- Optional: up to 40 GPIO
-
VDX-DIP-PCIRD
System on Module - ICOP Proprietary$171.00- DM&P SoC Vortex86DX- 800MHz
- 256MB DDR2 onboard
- 5S / 4U / LAN / IDE / PCI / 32GPIO / PWM
- Onboard 4MB SPI Flash
- 204-pin module, 204 pins for for PCI & Multi-I / O
- Support LPC Bus
- 70 x 45mm, DC +5V @ 340mA
- Optional: up to 3 PWM
-
VDX-DIP-ISARD
System on Module - ICOP Proprietary$171.00- DM&P SoC Vortex86DX- 800MHz
- 256MB DDR2 onboard
- 5S / 4U / LAN / IDE / ISA / 32GPIO / PWM
- Onboard 4MB SPI Flash
- 204-pin module, 204 pins for for ISA & Multi-I / O
- Support LPC Bus
- 70 x 45mm, DC +5V @ 320mA
- Optional: up to 3 PWM
-
VDX-6319RD-FC-D
System on Module - ICOP Proprietary$226.00- DM&P SoC Vortex86DX- 800MHz
- 256MB DDR2 onboard
- 2S / U / LPT / 16GPIO
- Onboard 4MB SPI Flash
- 128-pin CPUmodule, 64-pin 16-bit x-ISA, 64-pin I / O
- Onboard 1GB EmbedDisk
- 65 x 45mm DC +5V @400mA
-
VDX-6300RD
System on Module - ICOP Proprietary$190.00- DM&P SoC Vortex86DX- 800MHz
- 256MB DDR2 onboard
- 5S / 3U / LAN / 28GPIO / CF / PWM
- Onboard 4MB SPI Flash
- 68-pin module
- 90 x 46mm, DC +5V @ 380mA
- Optional: up to 24 PWM
-
SOM304SX-31VINE1
System on Module - ICOP Proprietary$190.00- DM&P SoC Vortex86SX- 300MHz
- 128MB DDR2 onboard
- 5S / 4U / VGA / LCD / LAN / LPT / 32GPIO / I2C / PWM / IDE
- Onboard 2MB SPI Flash
- 304-pin module, Standard ISA bus
- Support LPC Bus
- 70 (L) x 70 (W) x 10.5 (H)mm, DC +5V @ 460mA
- Optional: Onboard flash up to 4GB
-
SOM304SX-31PINE1
System on Module - ICOP Proprietary$177.00- DM&P SoC Vortex86SX- 300MHz
- 128MB DDR2 onboard
- 4S / 4U / LAN / LPT / 32GPIO / PWM / IDE / PCI / ISA
- Onboard 2MB SPI Flash
- 304-pin module, PCI, standard ISA bus
- Support LPC Bus
- 70 (L) x 70 (W) x 10.5 (H)mm, DC +5V @ 380mA
- Optional: Onboard flash up to 4GB
-
SOM200SX-31XIBE1
System on Module - ICOP Proprietary$165.00- DM&P SoC Vortex86SX- 300MHz
- 128MB DDR2 onboard
- 5S / 4U / LAN / LPT / 32GPIO / PWM / IDE
- Onboard 2MB SPI Flash
- 200-pin module, 16-bit x-ISA
- Support LPC Bus
- 52 (L) x 52 (W) x 10.5 (H)mm, DC +5V @ 240mA
- Optional: Onboard flash up to 4GB
-
SOM200SX-31PCNE1
System on Module - ICOP Proprietary$165.00- DM&P SoC Vortex86SX- 300MHz
- 128MB DDR2 onboard
- 5S / 4U / LAN / LPT / 32GPIO / PWM / IDE / PCI
- Onboard 2MB SPI Flash
- 200-pin module, Standard PCI bus
- Support LPC Bus
- 52 (L) x 52 (W) x 10.5 (H)mm, DC +5V @ 300mA
- Optional: Onboard flash up to 4GB
-
SOM200RD-52XINE1
System on Module - ICOP Proprietary$198.00- DM&P SoC Vortex86DX- 800MHz
- 256MB DDR2 onboard
- 5S / 4U / LAN / LPT / 32GPIO / I2C / PWM / IDE
- Onboard 4MB SPI Flash
- 200-pin module, 16-bit x-ISA
- Support LPC Bus
- 52 (L) x 52 (W) x 10.5 (H)mm, DC +5V @ 600mA
- Optional: Onboard flash up to 4GB, up to 32 PWM
