EBOX-3350DX3-C2AP

US$ 185.00

  • DM&P 32-bit x86 Vortex86DX3 Dual Core 1.0GHz SoC
  • 1GB DDR3-1600MHz onboard
  • SD card lot x1 (SD, SDXC)
  • 10/100 Mbps LAN x1
  • USB 2.0 port x3
  • RS-232 port x2
  • Fanless design
  • PXE Diskless Boot
  • Ultra low power
  • Auto Power On support
  • 75 x 75mm VESA Standard
  • Operation Temp. 0~60 ℃


Shipping & Availability
Standard Lead Time: 10–15 Business Days
Ships from Taiwan. Contact us for bulk pricing and availability.

Availability: In stock

Product total
Options total
Grand total
SKU: EBOX-3350DX3-C2AP Category: Tag: Brand:
Send Inquiry

EBOX-3350DX3-C2AP is a fanless embedded computer built on the 32-bit x86 Vortex86DX3 dual-core 1.0GHz SoC, with 1GB onboard DDR3-1600MHz memory. It features an SD/SDXC card slot, one 10/100 Mbps LAN port, three USB 2.0 ports, and two RS-232 ports, along with PXE diskless boot and Auto Power On support in a compact 75 x 75mm VESA-standard form factor.

The Vortex86 SoC series powers this platform — a family of 32-bit x86 processors compatible with Windows, Linux, and popular 32-bit RTOS, ranging from single-core 300MHz to dual-core 1GHz, with integrated L1/L2 cache and built-in ISA, PCI, PCIe, UART, IDE/SATA, I2C, SPI, CAN, GPIO, and USB interfaces in a single BGA package.

Website: http://www.vortex86.com/



Benchmark & Power Consumption index

EBOX-3350DX3-C2AP





EBOX-3350DX3-C2



Weight 350 g
Dimensions 95 × 95 × 35 mm
RAM

1GB
I/O Interface

USB, LAN

Specifications

Processor DM&P 32-bit x86 Vortex86DX3 Dual-core 1.0GHz SoC
BIOS AMI BIOS
Memory 1GB DDR3-1600MHz onboard
VGA Integrated Graphics Chip/D-Sub 15-pin (MAX. 1920 x 1080 pixels)
Ethernet RDC R6040 10/100 Mbps LAN x1
USB USB V2.0 x3 (Front x2, Rear x1)
HD Audio Realtek ALC262VD Mic-in & Line-out
SD card slot SD Slot x1 IDE Primary Channel/Internal SD x1 (Optional)
RS-232 D-Sub 9-pin connector x2
Auto Power On Support
Power requirement DC +5V/2A
Dimensions 95 x 95 x 35mm/VESA 75 x 75mm Support
Net Weight 350g
Operation Temperature 0~+60℃
Certifications CE, FCC, VCCI
OS Support Windows 7, WES7, Windows XP, XPe, CE6.0, Compact 7 and Linux

Distributor

Distributor: https://www.icop.com.tw/distributors

ebox-335xdx3_series_specifications

Download

ebox-335xdx3_user_manual

Download
