ICOP Technology Inc.
-
QEC-RXXCFFG
複合式輸入輸出模組 US$ 249.00EtherCAT Compound SubDevice (32 DIO + 2 AIO + COM port)
- EtherCAT 一致性測試工具通過驗證
- 隔離式 16 通道數位輸入與 16 通道數位輸出
- 數位輸出負載額定電壓高達 60VDC
- 支援 1 通道 16 位元 DAC 與 1 通道 16 位元 ADC 介面
- 支援 1 個標準 RS232/485 序列埠
- 支援 EtherCAT 分散時脈 (DC) 模式和 SM 模式
- 內部監控硬件信息
認證:
Shipping & Availability
Standard Lead Time: 10–15 Business Days
Ships from Taiwan. Contact us for bulk pricing and availability. -
QEC-M-02
MDevice – 緊湊型尺寸 US$ 450.00EtherCAT 主站系統。
- 內建 86Duino IDE，支援 C/C++ 程式設計及函式庫
- 專用核心用於即時 EtherCAT 主站通訊
- HDMI 顯示輸出（1280 x 720，256 色），支援圖形函式庫
- 16 通道隔離式數位輸入與 16 通道隔離式數位輸出
- 工作溫度：-20°C 至 +70°C（可選 -40°C 至 +85°C）
- 支援 EtherCAT、Giga LAN、USB、COM、HDMI、旋轉開關及 RUN/STOP 開關
認證:
Shipping & Availability
Standard Lead Time: 10–15 Business Days
Ships from Taiwan. Contact us for bulk pricing and availability. -
VSX-6153-V3
PC/104 單板電腦 US$ 236.00- DM&P SoC Vortex86SX- 300MHz
- 256MB DDR2 板載
- 4S / 2U / VGA / LCD / LAN / LPT / SPI / 16GPIO / IDE / CF
- 工作溫度: -20 ~ +70°C / -40 ~ +85°C (可選配)
- 2MB 的 SPI 快存磁碟板載
- 可選配: USB 音頻控制器
Shipping & Availability
Standard Lead Time: 10–15 Business Days
Ships from Taiwan. Contact us for bulk pricing and availability. -
EBOX-3350EX-AP
嵌入式迷你工控電腦 US$ 142.00-
- DM&P 32-bit x86 Vortex86EX 400MHz SoC
- 512MB DDR3 板載
- SD 卡插槽 x1 (SD, SDXC)
- 無風扇設計
- RDC R6040 10/100 Mbps 網路 x1
- USB 2.0 連接埠 x2
- Auto Power On 自動開機
- PXE 網路開機
- 超低功耗
- 支援 75 x 75mm VESA 標準
- 操作溫度 -40~+85°C
Shipping & Availability
Standard Lead Time: 10–15 Business Days
Ships from Taiwan. Contact us for bulk pricing and availability. -
-
EBOX-3350EX-C2AP
嵌入式迷你工控電腦 US$ 160.00-
- DM&P 32-bit x86 Vortex86EX 400MHz SoC
- 512MB DDR3 板載
- SD 卡插槽 x1 (SD, SDXC)
- 無風扇設計
- RDC R6040 10/100 Mbps 網路 x1
- USB 2.0 連接埠 x2
- RS232 連接埠 x2
- Auto Power On 自動開機
- PXE 網路開機
- 超低功耗
- 支援 75 x 75mm VESA 標準
- 操作溫度 -40~+85°C
Shipping & Availability
Standard Lead Time: 10–15 Business Days
Ships from Taiwan. Contact us for bulk pricing and availability. -
-
EBOX-TGL-35G7
嵌入式迷你工控電腦DDR4 8GB, M.2 2280 PCIe Gen.4×4 512GB (TLC) SSD w/ Windows 11 IoT 2021 LTSC Value Image preinstalled
-
- Intel® Tiger Lake i5-1135G7 Processor (Quad core 2.4GHz)
- DDR4 3200MHz Dual Channel SO-DIMM x2, memory up to 64GB
- HDMI 2.0 x2 (Max. 4096×2160@60Hz)
- DP 1.4 x2 (Max. 4096×2304@60Hz)
- Support Four Displays (4K HDR Displays or One 8K SDR Displays (DP)
- M.2 M-key x1 (2242/2280), PCIe Gen.4 x4 interface support NVMe SSD
- M.2 E-key x1 (2230), USB2.0/PCIe interface (CNVi supported) WLAN/BT
- Intel® i219-LM 1.0GbE, i225-V 2.5GbE (Built-in PXE diskless boot)
- COM1/COM2 RS232/485/422
- COM3/COM4 RS232; GPIO x1
- Operating Temperature -20°C to +60°C
Shipping & Availability
Standard Lead Time: 10–15 Business Days
Ships from Taiwan. Contact us for bulk pricing and availability. -
-
EB-58N-L2T4F-AP
嵌入式迷你工控電腦-
- Intel® Celeron N3160 Quad-core 1.6GHz
- AMI UEFI and Legacy mode BIOS switchable
- M.2 E-key x1 (2230), PCIe x1 interface (WLAN/BT)
- Auto Power On/PXE Diskless Boot
- RS-485 x4 (2 x Opto-Isolated), Lockable 8-pin 5.0mm Screw Terminal Block
- DC In +15V~56V Lockable Terminal Block Connector
- VESA and DIN Rail support
- 工作溫度: 0~+60°C
- 作業系統支援 Win 10 / Win 10 IoT / Win 7 / WES7 / Ubuntu / Debian / OpenSUSE / Fedora / Android-x86
Shipping & Availability
Standard Lead Time: 10–15 Business Days
Ships from Taiwan. Contact us for bulk pricing and availability. -
-
EB-58E-L2T4F-AP
嵌入式迷你工控電腦-
- Intel® Atom x5-E8000 Quad-core 1.04GHz
- AMI UEFI and Legacy mode BIOS switchable
- M.2 E-key x1 (2230), PCIe x1 interface (WLAN/BT)
- Auto Power On/PXE Diskless Boot
- RS-485 x4 (2 x Opto-Isolated), Lockable 8-pin 5.0mm Screw Terminal Block
- DC In +15V~56V Lockable Terminal Block Connector
- VESA and DIN Rail support
- 工作溫度: 0~+60°C
- 作業系統支援 Win 10 / Win 10 IoT / Win 7 / WES7 / Ubuntu / Debian / OpenSUSE / Fedora / Android-x86
Shipping & Availability
Standard Lead Time: 10–15 Business Days
Ships from Taiwan. Contact us for bulk pricing and availability. -
-
RJ-45 Cable (for EtherCAT use)
EtherCAT 周邊配件- Using for EtherCAT
- RJ-45 15cm x 5 pieces per pack
- RJ-45 30cm x 5 pieces per pack
- RJ-45 100cm x 2 pieces per pack
Shipping & Availability
Standard Lead Time: 10–15 Business Days
Ships from Taiwan. Contact us for bulk pricing and availability. -
EBOX-EHL-6412
嵌入式迷你工控電腦DDR4 8GB, M.2 2280 PCIe Gen.4×4 512GB (TLC) SSD w/ Windows 10 IoT 2021 LTSC Entry Image preinstalled.
-
- Intel® Elkhart Lake J6412 (Quad core 2.0GHz)
- DDR4 3200MHz SO-DIMM，記憶體最高可達 32GB
- HDMI 2.0 x2 (Max. 4096×2160@60Hz)
- DP 1.4 x1 (Max. 4096×2160@60Hz)
- Support Triple Displays
- M.2 M-key x1 (2260/2280), PCIe Gen.3 x2/SATA interface support NVMe SSD
- M.2 E-key x1 (2230)，USB2.0/PCIe x1 介面（支援 CNVi），可擴展 WLAN/BT
- Intel® i225-V 2.5GbE RJ45 x2 (Built-in PXE diskless boot)
- COM x1 (RS232/485/422), GPIO x1
- Operating Temperature -20~+60°C
Shipping & Availability
Standard Lead Time: 10–15 Business Days
Ships from Taiwan. Contact us for bulk pricing and availability. -
-
Eurostyle Terminal Cable (20 pieces per pack)
EtherCAT 周邊配件- Double-Sided Eurostyle Terminal Cable
- UL 1007-20AWG, Cable Length: 30 cm / 40 cm
- 20 pieces per pack
Shipping & Availability
Standard Lead Time: 10–15 Business Days
Ships from Taiwan. Contact us for bulk pricing and availability. -
QEC-M-150T
MDevice – 開放式框架 US$ 650.00EtherCAT MDevice Open-frame 15” LCD.
- 基於即時雙核心 CPU 的整合式 EtherCAT MDevice
- 86Duino 集成開發環境（IDE）
- 15″ TFT LCD with Resistive Touchscreen (1024×768)
- 適用於人機介面 (HMI) 的高可靠性 SLC eMMC 儲存裝置，具備 HDMI 輸出功能
- Industrial Operating Temperature 0 to +50°C/-20 to +60°C (Option)
- 豐富的介面：3×LAN、3×USB、RS232/485、CAN、SPI、I2C、與 Arduino 相容的 GPIO
- 內建電壓、溫度及系統狀態監控功能
認證:
Shipping & Availability
Standard Lead Time: 10–15 Business Days
Ships from Taiwan. Contact us for bulk pricing and availability.
